J1962 OBD2 16 Pins Male to Open End Pigtail OBD Cable

The OBD2 16-Pin Diagnostic Extension Cable is a professional-grade pigtail connector designed for automotive diagnostics, testing, and custom integration projects. Featuring a standard J1962 male connector with open wire leads, it enables seamless connection to OBD2-compliant vehicles and diagnostic systems. Ideal for workshops, technicians, and developers, this cable supports CAN and K-Line communication while delivering reliable signal transmission for accurate diagnostics and system development applications.

J1962

Main Features

Standard 16-Pin OBD2 Interface – Designed with a universal J1962 connector compatible with most OBD2-compliant vehicles manufactured after 1996, ensuring broad applicability across automotive platforms.
Open Wire Pigtail Configuration – Provides direct access to all 16 pins via exposed, colour-coded wires, enabling flexible integration into custom diagnostic, testing, or embedded system applications.
Comprehensive Protocol Support – Supports key automotive communication lines including CAN High/Low, K-Line, and power/ground connections for accurate signal interfacing.
High-Quality Cable Construction – Manufactured using durable materials to ensure flexibility, longevity, and reliable performance in workshop or development environments.
Custom Integration Capability – Ideal for engineers and technicians building bespoke diagnostic tools, data loggers, or vehicle communication systems.
Accurate Signal Transmission – Designed as a passive connector to maintain signal integrity between the vehicle and connected diagnostic equipment.
Colour-Coded Wiring Identification – Simplifies installation and troubleshooting by clearly differentiating pin connections for each signal line.
Wide Application Range – Suitable for automotive diagnostics, ECU communication, prototyping, testing rigs, and repair environments.

Package Includes

16-Pin OBD2 Pigtail Connector Cable
Protective Packaging

Professional OBD2 Connectivity & Integration Features

Standard 16-pin OBD2 J1962 connector

Open wire pigtail for custom applications

Supports CAN, K-Line and OBD protocols

Compatible with OBD2-compliant vehicles

Durable and flexible cable construction

Ideal for diagnostics, testing and DIY projects

Reliable signal transmission performance

Colour-coded wiring for easy identification

Suitable for workshop and development use

Plug-and-play physical interface

OBD2 diagnostic extension cable open wire harness

OBD2 16-Pin Diagnostic Extension Cable

Technical Specifications

Connector Length: 30cm

Cable Type: J1962 Make to Pigtail

Compatible Devices: OBD2 Cars

Other Special Features: 16 Pin J1962 OBD2 OBD-II Male Connector to Open Plug Wire, 30cm (12''), OBD Diagnostic Extension Cable Pigtail for DIY, OBD2 Male Connector Extension Pigtail Cable Adapter

Connector Gender: Male-to-Pigtail

Number of Pins: 16

Connectivity Technology: OBD2

Maximum Voltage: 16 Volts

OBD2 pigtail wiring harness for diagnostics
